DK60-B-T Series 3-Way Vertical Brass Motorized Ball Valve for Flow Direction Control

The DELCO DK60-B-T is a compact brass electric ball valve featuring a vertical 3-way (L/T port) design, ideal for diverting, mixing, and switching flow in pipelines. Its brass body provides reliable corrosion resistance, while the integrated structure ensures fast response and stable performance for small-scale fluid control systems.

Size Range: DN15-DN25

Material: Brass, Stainless Steel, Plastic etc.

Connection Standard: G / NPT

Get Free Quote

Features

Vertical 3-Way Design for Complex Flow Diversion and Automation

✅ Vertical 3-Way Structure (L/T Pattern): Adopts a vertical installation tee structure (L-shaped or T-shaped) to effectively achieve flow diversion, mixing, or switching of flow directions in complex pipeline layouts.

✅ Durable Brass and Stainless Steel Construction: The valve body and key components are made of brass for good corrosion resistance and mechanical strength. The stainless steel ball and PTFE/FKM sealing are suitable for water, gas, and non-corrosive liquids.

✅ Miniature Integrated and Space-Saving Design: The actuator is directly integrated with the miniature brass body, resulting in a small external volume that is convenient for installation on small equipment and instrument products.

✅ High Performance Actuator and Control: The integrated electric actuator drives the ball 90° or 180° to achieve accurate directional control. It offers rapid response and reliable, stable action.

✅ Multiple Voltage Adaptability and Versatile Functions: Supports a wide range of rated voltages (e.g., AC/DC 9-24V up to AC/DC 110-230V). The valve is suitable for cutting off, distributing, or switching the flow direction of media.
