DK60-B2 Miniature Electric Brass Ball Valve with Timer Function for Automatic Drain System

✅ Integrated Time Control Functionality: Features a unique built-in timer (0H:0M:0S to 99H:59M:59S) that automatically controls the duration the valve remains open, providing precision scheduling for water-saving and batch processing systems.

✅ High-Endurance Service Life: Engineered for long-term reliability, the valve is rated for a minimum of 100,000 opening/closing cycles, significantly exceeding typical operational demands in domestic or light industrial applications.

✅ Durable and Compact Brass Construction: The valve body is made of brass (nickel-plated optional) with FKM/PTFE sealing, capable of handling water and air up to 1.0MPa pressure in a liquid temperature range of 2℃-90℃.

✅ Secure and Waterproof Actuator: The actuator, made of engineering plastics, boasts an IP67 protection class, providing complete dust protection and resistance against temporary water immersion, ensuring stable operation in humid or outdoor environments.

✅ Wide Voltage Adaptability and Quick Action: Supports both low voltage (DC9-24V) and high voltage (AC/DC110-230V) options. The actuator provides a quick open/close time of ≤ 7seconds.
